Selected Problem Answers

  1. For the beam shown below draw the influence lines for $A_y$, $C_y$, $V_B$ and $M_B$ using the equilibrium method. Find the maximum possible value of $A_y$ if a $32\mathrm{\,kN/m}$ distributed load and a single $50\mathrm{\,kN}$ point load may be placed anywhere on the beam.
  2. For the beam shown below draw the influence lines for $B_y$, $D_y$, $V_C$ and $M_C$ using the equilibrium method. Find the maximum possible value of $M_C$ if a $32\mathrm{\,kN/m}$ distributed load and a single $50\mathrm{\,kN}$ point load may be placed anywhere on the beam.
  3. For the beam shown below draw the influence lines for $A_y$, $M_A$, $V_B$ and $M_B$ using the equilibrium method. Find the maximum possible value of $M_A$ if a $32\mathrm{\,kN/m}$ distributed load and a single $50\mathrm{\,kN}$ point load may be placed anywhere on the beam.
  4. For the beam shown below draw the influence lines for $A_y$, $C_y$, $E_y$, $M_B$ and $V_D$ using the equilibrium method. Find the maximum possible value of $V_D$ if a $32\mathrm{\,kN/m}$ distributed load and a single $50\mathrm{\,kN}$ point load may be placed anywhere on the beam.
  5. For the frame shown below draw the influence lines for $E_y$, $F_y$, $V_C$ and $M_C$ using the equilibrium method.

  6. For the frame shown below draw the influence lines for $D_y$, $E_y$, and $M_D$ using the equilibrium method.
  7. For the beam shown below draw the influence lines for $A_y$, $C_y$, $M_A$ and $V_B$ using the Müller-Breslau Principle.
  8. For the beam shown below draw the influence lines for $A_y$, $C_y$, $M_B$ and $V_B$ using the Müller-Breslau Principle.
  9. For the beam shown below draw the influence lines for $A_y$, $C_y$, $D_y$, $V_B$, and $M_C$ using the Müller-Breslau Principle.
  10. For the beam shown below draw the influence lines for $A_y$, $C_y$, $M_B$ and $V_B$ using the Müller-Breslau Principle.
  11. For the truss shown below draw the influence lines for $A_y$, $E_y$, $F_{AH}$ and $F_{BC}$ for a moving load between A and E.
  12. For the truss shown below draw the influence lines for $F_{AF}$, $F_{FH}$, $F_{BH}$ and $F_{BC}$ for a moving load between A and E. Find the maximum force in member AF caused by a moving truck that travels between A and E (in either direction) and has the wheel load pattern shown below.
